Frame |
Carbon technology frame, disc, BSA, 142x12 mm thru axle, flat mount 160/160 mm, internal cable routing |
Fork |
Paralane Carbon disc, integrated cable routing, disc, 100x12 mm, flat mount |
Shifter |
Shimano Ultegra R8170 Di2, 12-speed |
Front derailleur |
Shimano Ultegra Di2 R8150, 12-speed |
Rear derailleur |
Shimano Ultegra Di2, RD-R8150, 12-speed |
Cassette |
Shimano Ultegra 8100, 12-speed, 11-34T |
Chain |
Shimano Ultegra CN-M8100, 12-speed |
Crankset |
Shimano Ultegra FC-R8100, 12-speed |
Transmission of drive |
front: 50/34, rear: 11-34 |
Chainring |
Shimano Ultegra 8100, 12-speed, 11-34T |
Bottom bracket |
Shimano BSA 68 |
Handlebar |
BBB Basic, aluminium, drop: 125 mm, reach: 70 mm |
Grips |
FOCUS Bartape SL |
Stem |
FOCUS C.I.S. 2.0 integrated, 31.8 mm, aluminium, with Garmin / Wahoo-Mount |
Headset |
ACROS, IS 52/40-IS52/42 |
Saddle |
Selle Royal Groove SRX |
Seatpost |
Easton EC70, carbon, 27.2 mm, set-back: 20 mm |
Brakes front | rear |
Shimano Ultegra Di2 BR-R8170, 12-speed | Shimano Ultegra Di2 BR-R8170, 12-speed |
Front brake disc |
160 mm |
Rear brake disc |
160 mm |
Wheelset |
DT Swiss ER1600, alloy, 622-22, 12x100 mm / 12x142 mm, 30 mm height |
Tyres front | rear |
Vittoria Rubino Pro TLR, 700 x 32C, Folding | Vittoria Rubino Pro TLR, 700 x 32C, Folding |
Weight |
8.6 kg (-) |
Permissible system weight |
120 kg |
