General
|
|
|
|
|
|
Total set weight
|
|
Rim: 1485
|
|
Recommended tyre width
|
|
Road tyres: 25 - 30mm
|
|
Gravel tires: 35 - 57mm
|
|
Maximum rider weight
|
|
Disc: no weight limit
|
|
Rim: 95kg
|
|
Rims*
|
|
Front
|
|
Rear
|
|
Rim height
|
|
30 mm
|
|
30 mm
|
|
External rim width
|
|
26 mm
|
|
26 mm
|
|
Internal rim width
|
|
19 mm
|
|
19 mm
|
|
Tubeless (ready)
|
|
Yes
|
|
Yes
|
|
Optimum tire width (mm)
|
|
25
|
|
25
|
|
Tire width compatibility (mm)
|
|
22- 57
|
|
22- 57
|
|
|
|
* Compatible with all clincher tires in combination with inner-tubes as well
|
|
Hubs
|
|
Front
|
|
Rear
|
|
Hubs
|
|
Scope S-series
|
|
Scope S-series
|
|
Bearings (Rim Brake)
|
|
Custom 2 x 61802
|
|
Custom 61802 + 61902
|
|
Engagement System
|
|
|
|
3-pawl
|
|
Axle System (Rim Brake)
|
|
QR 100 mm
|
|
QR 130 mm*
|
|
Brake interface (Disc)
|
|
Centerlock
|
|
Centerlock
|
|
* Special end-caps available for different axle configurations
|
|
Spokes
|
|
Front
|
|
Rear
|
|
Spoke count (Rim Brake)
|
|
18
|
|
21
|
|
Spoke type (Rim Brake)
|
|
Sapim CX - Leader
|
|
Sapim CX - Leader
|
